Solar PV Panel Recycling Machine

Solar PV Panel Recycling Machine

A Solar PV Panel Recycling Machine is specifically designed to handle end-of-life photovoltaic modules, achieving the separation and recovery of aluminum frames, glass, copper, silicon powder, silver, and plastics.

Product Description

Most materials of waste soalr PV modules can be recycled, including 65%-7% glass, 10%plastic(encapsulant and backsheet), 3%-5%silicon and 1% copper and less than 0.1% of silver, tin and lead, although the content is small, but the recycling value is large. The recovery rate can reach to more than 98%.

Raw Materials

Recycling Pv Panel Components
Solar PV Panels

Solar PV Panels

Solar Panels

Solar Panels

Solar Panel Recycling

Waste Solar Panel

Composition Analysis of Solar Panels

The most commonly photovoltaic panel waste in the market consists of monocrystalline silicon solar panels, polycrystalline silicon solar panels, and bifacial solar panels.

Final Product

Aluminum Frame

Aluminum Frame

Plastic

Plastic

Solar Panel Glass

Glass

Copper

Copper

Photovoltaic Panels

Photovoltaic Panels

Copper Solder Strip

Copper Solder Strip

Silicon Powder

Silicon Powder

Silver Ingot

Silver Ingot

The Solar Panel Recycling Machine primarily employs a combination of physical, chemical, and thermal processing techniques to handle various types of photovoltaic panels, achieving the separation and recovery of aluminum frames, glass, metals, silicon powder and plastics.

Aluminum frame removal rate ≥ 99%, recycling purity ≥ 98%.

Glass removal rate 85-95%, recycling purity ≥ 90%.

Metal particle (copper) recovery rate ≥ 95%, recycling purity ≥ 95%.

Plastic powder recovery rate ≥ 95%, recycling purity ≥ 90%.

Silicon recovery rate 95%, appears in the form of a mixture of plastic powder, glass powder, etc., with a silicon content of about 45%.

Flow Chart

Solar PV Panel Recycling Machine Process

Guanma Machinery Waste Solar PV Panel Recycling Process
Silver and Silicon Powder

Metal particle (copper) recovery rate ≥ 95%, recycling purity ≥ 95%.

Glass

Glass removal rate 85-95%, recycling purity ≥ 90%.

Copper Powder

Metal particle (copper) recovery rate ≥ 95%, recycling purity ≥ 95%.

1.Frame Removal Machine

Aluminum Frame Removing Machine
Technical ParametersSpecification
Capacity40-70PCS/h
Raw Material SizeLength(mm):1000-2400 Width(mm):800-1300
Power4Kw
Size of Machine2100X2140X2130mm
Operating ModeAutomated/Semi-automated
Weight1200KG

The fully automatic pv panel frame removal machine uses the hydraulic disassembly principle to efficiently and safely remove the aluminum frame of the photovoltaic panel for recycling. It can be used for photovoltaic panels of different sizes and models.

2.Glass Removal Machine

Glass Removing Machine
Technical ParametersSpecification
Capacity40-70PCS/h
Raw Material SizeLength(mm):1000-2400 Width(mm):800mm-1300mm
Power30Kw
Operating ModeAutomated
Weight7.5T

The photovoltaic panel glass removal machine is a device specially used to separate the glass layer of photovoltaic panels from other components (such as silicon circuit chips, packaging materials, backplanes, etc.).

3.Crushing and Sorting Production Line

Finished ProductSeparation RatePurity
Mixed Metal95%95%
Plastic95%90%
Silicon95%

The crushing and sorting production line mainly processes the back panel raw materials mainly composed of copper, silver and silicon powder after removing the aluminum frame and glass. After the main pre-treatment crushing, crushing and grinding, the plastic and metal are separated.

4.Pyrolysis Process Line

After removing the aluminum frame and glass, the remaining materials (mainly silicon, metals, cables, etc.) are directly fed into the pyrolysis treatment line. producing combustible gases, liquid oil, and solid residues (such as metal oxides, silicon powder, etc.).

5.Extraction of Precious Metal

After crushing or pyrolysis, the metal content mainly is copper, also will have some silver mixed in silicon. Will use precious refining machine to extraction silver, to get purity silver.

Product Advantages

1.High separation rate: frame remove rate≥99%, glass remove rate 85-95%, metal separation rate≥95%;

2.Reasonable layout, stable performance and low noise;

3.PLC control system can improve work efficiency and save labor cost.

4.The whole system adopts closed operation, negative pressure
transfer. Dust can be collected effectively. There is no dust leakage. System is safety and environmental protection.

Technical Parameter

Solar PV Panel Recycling Machine Technical Parameters

Working voltage can be customized, and if you have other requrement and want to know more details, please contact us.(The data in this table are for reference only)

Model Capacity kg/h Power/kw Size L*W*H(m)
SPR-500 100-500kg 138kw 30*7*5m
SPR-1000 500-1000kg 285kw 45*7*5m
SPR-2000 1000-2000kg 380kw 65*20*6m
SPR-3000 2000-3000kg 485kw 100*25*6m
Note: The bigger capacity can be customization.
